• Definition of ARDS: a type of diffuse, inflammatory lung injury, leading to increased pulmonary vascular permeability, increased lung weight and loss of aerated lung tissue (Ranieri et al., 2012).
• Associated with high morbidity and mortality affecting close to 200,000 individuals per year and responsible for 74,500 deaths per year in the United States (Rubenfeld et al., 2005).
• Clinical manifestations:
  • Life threatening acute hypoxic respiratory failure
  • Radiographic appearance of diffuse bilateral opacities (Howell & Davis, 2018).
    • Opacities are the result of neutrophil, macrophage, and dendritic cell mediated tissue damage in the alveoli.
    • In the setting of overall inflammatory state of the acute illness:
      • Increased vascular permeability
      • Release of inflammatory cytokines
      • Accumulation of protein rich fluid in the alveoli resulting in impaired gas exchange (Han & Mallampalli, 2015) and subsequent hypoxia
      • Diffuse alveolar damage
    • Alveolar damage increases physiologic dead space and increases lung compliance
• Conditions associated with the development of ARDS:
  • Sepsis from either a pulmonary or non-pulmonary source accounts for 79% of cases (Rubenfeld et al., 2005).
  • Other conditions: aspiration, pneumonia, toxic inhalation, lung contusion, trauma, acute pancreatitis, blood product transfusion, burn injury, drowning related lung injury, cardiopulmonary bypass (Howell & Davis, 2018; Rubenfeld et al., 2005).
  • Not all those that develop the above conditions go on to develop ARDS.

• Treatment:
  • Supportive
    • Limited evidence-based therapies known to reduce mortality and treatment remains supportive.
    • Mechanical ventilator support is the cornerstone of therapy.
      • May further potentiate lung injury.
  • Continued treatment of underlying issues that led to development of ARDS.

• Timing
  • Within one week of clinical insult or new or worsening respiratory symptoms.
• Imaging
  • Bilateral opacities not explained by effusion, lobar/lung collapse or nodules.
• Origin of edema
  • Respiratory failure cannot be fully explained by cardiac failure or volume overload.
    • Consider ECHO or further evaluation of hydrostatic etiologies of pulmonary edema if not risk factors.
• Oxygenation (degree of hypoxemia) and classification of ARDS (Ranieri et al. 2012)
  • Mild - PaO2/FiO2 ratio of 201-300 mmHg with PEEP or CPAP ≥ 5cm H2O
  • Moderate - PaO2/FiO2 ratio of 101-200 mmHg with PEEP ≥ 5cm H2O
  • Severe - PaO2/FiO2 ratio £ 100 mmHg with PEEP ≥ 5cm H2O

• All patients with ARDS
  • Lower tidal volume mechanical ventilation (4-8 ml/kg predicted body weight) and lower plateau pressures < 30cm H2O
  • Prone positioning for > 12 hours/day in those with severe ARDS
• Patients with moderate to severe ARDS
  • Higher PEEP as opposed to lower PEEP
  • Recruitment maneuvers (RMs)
  • Both higher PEEP and RMs are thought to decrease atelectasis and improve end- expiratory lung volumes.

Recommendation against the routine use of high frequency oscillatory ventilation in those with moderate to severe ARDS (Fan et al. 2017).
There is no specific recommendation for or against the use of ECMO for patients with severe ARDS, citing the need for additional research.

To best understand and interpret the recommendations for ARDS, the following concepts regarding mechanical ventilation should be understood.

• Low tidal volume ventilation (also referred to as long protective ventilation)

• Refers to target tidal volumes of 4 to 8 mL/kg of predicted body weight in patients with ARDS as opposed to traditional ventilator tidal volume goals ranging between 8-12 mL/kg.
• Target inspiratory plateau pressure £ 30 cm H2O
  • Plateau pressure: the pressure applied to small airways and alveoli (a measurement of compliance), measured at the end of inspiration during an inspiratory pause (when there is no flow in the circuit).
• May require permissive hypercapnia
  • A ventilator strategy in which there is expected hypoventilation of the alveoli which can minimize alveolar hyperinflation and ventilator associated lung injury.

• Prone Positioning
  • Involves placing patient in prone position while on ventilator, shifts weight of heart to ventral wall.
    • Goals:
      • Increase gas exchange by recruiting non-aerated alveoli, keeping alveoli open longer.
      • Improves ventilation-perfusion (VQ) matching (delivering oxygen into bloodstream more efficiently).
      • Increases end expiratory lung volume.
      • Decreased ventilator induced lung injury (VILI) via uniform distribution of tidal volume lung recruitment and alteration in chest wall mechanics (Gattinoni, 2013).
  • Prone positioning requires multiple staff members and a high degree of proficiency to facilitate the process.
  • Contraindicated in patients with increased intracranial pressure, severe hemoptysis, pregnancy, recent sternal surgery, new deep vein thrombosis or unstable fracture.
• PEEP (Positive End Expiratory Pressure)
  • Pressure remaining in lungs at end of expiration
  • Keeps alveoli open longer
  • Potential for barotrauma
  • Usually balance PEEP/FiO2 to optimize oxygen while minimizing barotrauma and oxygen toxicity
• Recruitment Maneuvers:
  • A transient, sustained increase in airway pressure with goal to open collapsed alveoli.
  • Requires applying adequate pressure (PEEP) to overcome distending pressure (the difference between airway pressure and pleural pressure) which is enough to open collapsed alveoli.
  • Involves applying high PEEP for a specified time and evaluating improvements in oxygenation.
    • Example: 30-40 PEEP for 30-40 seconds
• Extra-Corporeal Membrane Oxygenation (ECMO):

• Veno-venous ECMO works by pulling blood from the inferior vena-cava through a circuit (outside of the body) which removes carbon dioxide and oxygenates blood returning it to the venous system via internal jugular vein.
• Only indicated in severe, refractory respiratory failure, refractory to mechanical ventilation
• Requires sedation
• Short term

• High Frequency Oscillation Ventilation (HFOV)
  • Delivery of small tidal volumes (0.1 – 3 ml/kg) at rapid rates (180-900 cycles per minute or 3-15 Hz)
  • Delivered via an oscillatory pump
  • Theoretically promotes maintenance of alveolar recruitment while preventing over distention
  • Not recommended in the treatment of ARDS

 Bellani, G., Laffey, J.G., Pham, T., Fan, E., Brochard, L., Esteban, A.,… Pesenti, A. (2016). LUNG SAFE Investigators; ESICM Trials Group. Epidemiology, patterns of care, and mortality for patients with acute respiratory distress syndrome in intensive care units in 50 countries. JAMA, 315(8), 788–800.
Doi: 10.1001/jama.2016.0291.

Fan, E., Del Sorbo, L., Goligher, E.C., Hodgson, C.L., Munshi, L., Walkey, A.J.,…Brochard, L.J. (2017).
An Official American Thoracic Society/European Society of Intensive Care Medicine/Society of Critical Care Medicine Clinical Practice Guideline: Mechanical Ventilation in Adult Patients with Acute Respiratory Distress Syndrome. American Journal of Respiratory and Critical Care Medicine, 195(9), 1253-1263.
doi: 10.1164/rccm.201703-0548ST
Imai, I. & Slutsky, A.S. (2005). High-frequency oscillatory ventilation and ventilator-induced lung injury. Critical Care Medicine,
33(2), S129-S134. DOI: 10.1097/01.CCM.0000156793.05936.81

Gattinoni, L., Pesenti, A., & Carlesso, E. (2013). Body position changes redistribute lung computed-tomographic density in patients with acute respiratory failure: impact and clinical fallout through the following 20 years. Intensive Care Med, 39(11), 1909–1915. Doi: 10.1007/s00134-013-3066-x

Han, S.H. & Mallampalli, R.K. (2015). The Acute Respiratory Distress Syndrome: From Mechanism to Translation. The Journal of Immunology, 194(3), 855-860.
DOI: https://doi.org/10.4049/jimmunol.1402513

Howell, M.D. & Davis, A.M. (2018). Management of ARDs in Adults. JAMA, 319(7), 711-712. Doi: 10.1001/jama.2018.0307

Ranieri, V.M., Rubenfeld, V.M., Thompson, B.T., Ferguson, N.D., Caldwell, E., Fan, E., Camporota, L. & Slutsky, A.S.; ARDS Definition Task Force. (2012). Acute respiratory distress syndrome: The Berlin Definition. JAMA, 307(23), 2526-2533. doi: 10.1001/jama.2012.5669
Rubenfeld, G.D., Caldwell, E., Peabody, E., Weaver, J., Martin, D.P., Neff, M., Stern, E.J., Hudson, L.D. (2005). Incidence and outcomes of acute lung injury. The New England Journal of Medicine, 353(16), 1685-1693. Doi: 10.1056/NEJMoa050333
